• Windows - Linux - MacOS. Logic 2.3.9 is a bug fix release, that covers several important CPU utilization bugs. Thanks to everyone who reported the problem, sent in captures, and worked with us to help find the root cause.
• Software isn’t included, instead you get instructions to download the latest version from the Saleae web site. We always download the latest software, so we appreciate that there’s one less CD.
• Due to saleae software limitations, only sample rates exposed in the Logic software can be used. Use the getallsamplerates method to get all of the valid sample rates. The list of valid sample rates changes based on the number and type of active channels, so set up all channel configuration before attempting to set the sample rate.
• Laden Sie die weltbeste und beliebteste Logic Analyzer-Software herunter.

Micro-Gripper Hooks, Saleae Carrying Case, USB 3.0 Cable, & the Getting Started Card. Logic Pro 16 includes: Saleae Logic Pro 16 USB Logic Analyzer, 4x 4-Channel Wire Harnesses, 32x Micro-Gripper Hooks, Saleae Carrying Case, USB 3.0 Cable, & the Getting Started Card Purchasing Additional Accessories.

• Mark
• on 31-08-2020

Download Links

Windows - Linux - MacOS

What's New

• Warning when a USB host controller driver is out of date and could cause device reliability problems.
• Analog interactions toolbar to easily navigate the analog data
• Mouse dragging of analog channels allows X and Y panning simultaneously (once a certain Y threshold is met)
• New analog keyboard shortcuts - zoom, pan and fit
• Scroll up and down the channels via space + scroll
• New preferences menu

Improvements

• Improved channels context (right click) menu
• Unsupported WebGL error handling
• Show a notification on device disconnection instead of creating a new tab

Bug fixes

• Missing analog calibration when loading a capture
• Fixed bug where extensions would not load and updates would not download if the internet connection used a proxy.
• Fixed bug where application would stop working properly after the system suspended and resumed.
• Fixed bug when loading extensions from a non-ascii path.

This library implements the control protocol for theSaleae Logic Analyzer. It is based off of thedocumentation and example here:https://github.com/saleae/SaleaeSocketApi

IMPORTANT: You must enable the ‘Remote Scripting Server’ in Saleae. Clickon “Options” in the top-right, the “Developer” tab, and check “Enable scriptingsocket server”. This should not require a restart.

This library requires Saleae Logic 1.2.x or greater. Unfortunately there is noway to check the version of Logic running using the scripting protocol so thisis difficult to check at runtime.

Currently, this is basically a direct mapping of API calls with some smallsanity checking and conveniences. It has not been extensively tested beyondmy immediate needs, but it also should not have any known problems.

To get a feel for how the library works and what it can do, try the built-in demo:

Issues, updates, pull requests, etc should be directedto github.

Installation¶

The easiest method is to simply use pip:

Usage¶

The Saleae class¶

exception CommandNAKedError[source]¶

exception ImpossibleSettings[source]¶

exception SaleaeError[source]¶

Start a new capture and immediately return.

Convenience method that blocks until capture is complete.

Stop a capture and return whether any data was captured.

Export analyzer index N and save to absolute path save_path. The analyzer must be finished processing

export_data2(file_path_on_target_machine, digital_channels=None, analog_channels=None, time_span=None, format='csv', **export_args)[source]¶

Export command:

EXPORT_DATA2,<filename>,[ALL_CHANNELS|SPECIFIC_CHANNELS, [DIGITAL_ONLY|ANALOG_ONLY|ANALOG_AND_DIGITAL], <channel index> [ANALOG|DIGITAL], …, <channel index> [ANALOG|DIGITAL]],[ALL_TIME|TIME_SPAN, <(double)start>, <(double)end>],[BINARY, <binary settings>|CSV, <csv settings>|VCD|MATLAB, <matlab settings>]

Get the active digital and analog channels.

Get the current active Saleae device.

Download Saleae Driver App

Get available sample rate combinations for the current performance level and channel combination.

Return a list of analyzers currently in use, with indexes.

Compute USB bandwidth for a given configuration.

Must supply sample_rate because Saleae API has no get_sample_rate method.

The number of samples saleae records before the trigger.

Get a list of attached Saleae devices.

Note, this will never be an empty list. If no actual Saleae devices areconnected, then Logic will return the four fake devices shown in theexample.

Get a list of available digital I/O voltage thresholds for the device and the currently active selection.

This feature is only supported on the original Logic 16, Logic Pro 8,and Logic Pro 16.

Get performance value. Performance controls USB traffic and quality.

check to see if analyzer with index N has finished processing.

Attempts to find and kill running Saleae Logic software

Attempts to open Saleae Logic software

Set all channels to active.

select_active_device(device_index)[source]¶

Set the active digital and analog channels.

Note: This feature is only supported on Logic 16, Logic 8(2nd gen),Logic Pro 8, and Logic Pro 16

Set the number of samples saleae records before the trigger.

Set the capture duration to a length of time.

Set active digital I/O voltage threshold for the device.

Download Saleae Driver Download

This feature is only supported on the original Logic 16, Logic Pro 8,and Logic Pro 16.

Set the capture duration to a specific number of samples.

From Saleae documentation

Note: USB transfer chunks are about 33ms of data so the number ofsamples you actually get are in steps of 33ms.

Set performance value. Performance controls USB traffic and quality.

Download Saleae Driver Windows 10

Note: This will change the sample rate.

#>>> s.set_performance(saleae.PerformanceOption.Full)

Set the sample rate. Note the caveats. Consider set_sample_rate_by_minimum.

Due to saleae software limitations, only sample rates exposed in theLogic software can be used. Use the get_all_sample_rates method toget all of the valid sample rates. The list of valid sample rateschanges based on the number and type of active channels, so set up allchannel configuration before attempting to set the sample rate.

Set to a valid sample rate given current configuration and a target.

Because the avaiable sample rates are not known until runtime after allother configuration, this helper method takes a minimum digital and/oranalog sampling rate and will choose the minimum sampling rate availableat runtime. Setting digital or analog to 0 will disable the respectivesampling method.

Convenience method to set one trigger.

Download Saleae Drivers License

Set the trigger conditions for all active digital channels.

Note: Calls to this function must always set all active digitalchannels. The Saleae protocol does not currently expose a method to readcurrent triggers.
